Advantages Of Metal Core PCB

Specialized Metal-Based PCB Manufacturing:

We focus on producing high thermal conductivity metal-based PCBs suitable for applications with high heat dissipation requirements.
Advanced Thermal Management Technology:

Our PCBs provide excellent heat dissipation performance, ensuring stable operation of electronic components in high-temperature environments
Multiple Material Options:

We offer various metal substrates, including aluminum and copper, to meet diverse application needs.
High Strength and Durability:

Our stringent manufacturing processes and quality control ensure that metal-based PCBs have high strength and a long lifespan.

Why Choose Us

Specialized Metal-Based PCB Manufacturing:

Our company specializes in the production of high thermal conductivity metal-based PCBs, leveraging advanced manufacturing techniques to ensure superior quality. These PCBs are designed to efficiently transfer heat away from critical components, making th
Advanced Thermal Management Technology:

We utilize cutting-edge thermal management technology in our metal-based PCBs to enhance heat dissipation performance. This ensures that electronic components can operate at optimal temperatures, reducing the risk of overheating and improving overall syst
Multiple Material Options:

To accommodate a wide range of applications, we offer a variety of metal substrate options, including aluminum, copper, and other specialized materials. Each material is chosen based on its thermal and electrical properties, allowing us to provide customi
High Strength and Durability:

Our manufacturing processes adhere to strict quality control standards, ensuring that our metal-based PCBs exhibit high strength and durability. We conduct rigorous testing at each production stage to confirm that our products can withstand demanding cond

Production Capacity

Feature	Capability
Quality Grade	Standard IPC 2
Number of Layers	4 – 24layers
Order Quantity	1pc – 10000+pcs
Material	Aluminum core (Domestic 1060), Copper core, FR4 covering
Board Size	Min 66mm \| Max 610610mm
Board Thickness	0.8mm – 5.0mm
Copper Weight (Finished)	0.5oz – 10.0oz
Min Tracing/Spacing	4mil/4mil
Solder Mask Sides	As per the file
Solder Mask Color	Green, White, Blue, Black, Red, Yellow
Silkscreen Sides	As per the file
Silkscreen Color	White, Black, Yellow
Surface Finish	* HASL – Hot Air Solder Leveling * Lead Free HASL – RoHS * ENIG – Electroless Nickle * Immersion Gold – RoHS
Min Annular Ring	4mil
Min Drilling Hole Diameter	6mil
Other Techniques	* Countersink holes * Screw holes

Frequently Asked Questions

What is the layer count that you can provide?: We can offer up to 24 to 40-layer boards with the highest degree of precision.

Which surface finishes you are providing for multilayer circuit boards?: For multilayer PCBs, we can offer following finishes
*Electroless Nickel / Immersion Gold
*Silver
*Electroless Tin Lead
*Organic (OSP)
*Hard Gold (edge contact)
*Carbon
*Peelable

What are your average delivery times for multilayer PCB manufacturing?: Our delivery schedule can range from 24 hours to 3 weeks depending on the project.

What is the difference between single layer and multilayer PCBs?: Single layer boards have just 1 layer and multilayer PCBs have multiple layers more than two.

How will Tuopst choose between quality and speed?: At Tuopst, we prioritize quality and efficiency as our core values. We understand the importance of timely execution for time-sensitive projects without compromising on production quality. Our commitment to speed encompasses rapid quotations, streamlined communication, personalized one-to-one service, and more. Rest assured that when you engage with us, our dedicated service begins irrespective of your final decision to choose our services or not.

What files do you require for PCB manufacturing?: To start PCB manufacturing, we would require various design files including Gerber Files, Bill of Materials (BOM) file, Assembly drawings, Preliminary files or any other special requirements file.
