Expert Rigid-Flex PCB Manufacturing

We specialize in producing high-quality rigid-flex PCBs, leveraging extensive experience and advanced equipment. Our rigid-flex PCBs are not only structurally reliable but also provide excellent electrical performance, making them ideal for compact and co
Support for Complex Designs

We offer multilayer, high-density rigid-flex PCBs that meet the needs of complex circuit designs and stringent space constraints. Whether for industrial control systems, medical devices, or consumer electronics, our products cater to demands for miniaturi
Flexible Customization

To meet the diverse needs of our clients, we provide flexible customization services. From material selection and thickness configuration to specialized functional designs, we tailor rigid-flex PCB solutions according to specific application requirements,
High Reliability and Durability

Every step of our rigid-flex PCB manufacturing process undergoes strict quality control to ensure high reliability and durability. Rigorously tested and inspected, our products perform consistently even under high stress and harsh environments, making the

Production Capacity

Items	Rigid-flex
Material	FR-4,FPC High-frequency
Layers	1-40L
Max cut lamination size	500*420mm
Final board thickness	0.20-6.0mm
Min Final Hole size	0.075mm
Aspect Ratio	14:01
Inner layer Line Width/Space	0.05mm
Copper Foil Thickness (Inner Layers)	1/6oz-1oz
Min dielectric layer thickness	20um
Copper Foil Thickness (Outer Layers)	1/3oz-1oz
Copper to drill distance	0.2mm
Out layer Line width/space	0.035mm
Min SMD width	0.05mm
Max Solder Mask Plug Hole Diameter	0.5mm
solder mask strip width	0.075mm
Final Set Size Tolerance	±0.1mm/limit±0.05mm
Min Hole to board edge Distance	0.075-0.15mm
Min Beveling angle Tolerance	±3-5°
Layer to layer Tolerance	≤0.075mm(1-6L）
Inner layer Min PTH Annular Ring	0.15mm
Out layer Min PTH Annular ring	0.15mm
Surface Treatment	OSP、HASL 、ENIG、Gold Finger、Plating Gold 、ENEPIG、IMM TIN、IMM AG
Warp&Twist	0.5%(less than 45u)

Frequently Asked Questions

What is the layer count that you can provide?: We can offer up to 24 to 40-layer boards with the highest degree of precision.

Which surface finishes you are providing for multilayer circuit boards?: For multilayer PCBs, we can offer following finishes
*Electroless Nickel / Immersion Gold
*Silver
*Electroless Tin Lead
*Organic (OSP)
*Hard Gold (edge contact)
*Carbon
*Peelable

What are your average delivery times for multilayer PCB manufacturing?: Our delivery schedule can range from 24 hours to 3 weeks depending on the project.

What is the difference between single layer and multilayer PCBs?: Single layer boards have just 1 layer and multilayer PCBs have multiple layers more than two.

How will Tuopst choose between quality and speed?: At Tuopst, we prioritize quality and efficiency as our core values. We understand the importance of timely execution for time-sensitive projects without compromising on production quality. Our commitment to speed encompasses rapid quotations, streamlined communication, personalized one-to-one service, and more. Rest assured that when you engage with us, our dedicated service begins irrespective of your final decision to choose our services or not.

What files do you require for PCB manufacturing?: To start PCB manufacturing, we would require various design files including Gerber Files, Bill of Materials (BOM) file, Assembly drawings, Preliminary files or any other special requirements file.
